NAGIN 1325S HSD Professional CNC Machine for Woodworking & Advertising
NAGIN-1325S-HSD
Detailed Description
The NAGIN S Stone Series is a reliable CNC machine built for high-precision processing of stone materials such as granite, marble, quartz, basalt, onyx, and engineered stone. Perfect for countertops, monuments, architectural carvings, and 3D reliefs.
A solid welded steel frame, powerful Italian HSD spindle (13–18 kW), Japanese servo motors, and Taiwan Syntec controller provide outstanding performance under heavy workloads. The motion system uses X/Y gear racks and a Z-axis TBI ball screw, ensuring up to ±0.02 mm accuracy.
Available with vacuum or T-slot table and multiple size options. Compatible with major CAM software. Backed by a 3-year warranty. NAGIN S Stone Series delivers strength, stability, and precision you can count on.
The NAGIN S Stone Series is a reliable CNC machine built for high-precision processing of stone materials such as granite, marble, quartz, basalt, onyx, and engineered stone. Perfect for countertops, monuments, architectural carvings, and 3D reliefs.
A solid welded steel frame, powerful Italian HSD spindle (13–18 kW), Japanese servo motors, and Taiwan Syntec controller provide outstanding performance under heavy workloads. The motion system uses X/Y gear racks and a Z-axis TBI ball screw, ensuring up to ±0.02 mm accuracy.
Available with vacuum or T-slot table and multiple size options. Compatible with major CAM software. Backed by a 3-year warranty. NAGIN S Stone Series delivers strength, stability, and precision you can count on.
Brand: NAGIN
Machine type: 3-axis CNC мachine
Control system: Syntec
Technical Specifications
- Working area: 1300×2500×200 mm (4×8 ft)
- Spindle: HSD 13 kW water-cooled, HSK-63F (optional 15 kW/18 kW)
- Frame: 30 mm steel, 3 ton capacity
- Guides: Hiwin 30 mm square rails
- Transmission: Rack & pinion (X/Y), TBI ball screw (Z)
- Table: T-slots + vacuum cups, water collection tray
- Lubrication: automatic
- Drives: Yaskawa servos + drivers
- Inverter: Delta VFD-B
- Tool sensor, tool set with cooling
- Speeds: rapid 30 m/min; cutting 20 m/min
- Power: AC 380 V, 50 Hz, 3 phases
- Control: Syntec CNC
- Options: 5-axis head, vacuum pump 5.5 kW, CW6200 chiller
