Insert router cutters to drill and edge Z=2+1
A0460
Detailed Description
Assembly router cutter with two replaceable HW (integral tungsten carbide) inserts, 1.5 mm thick, and one brazed Hc (brazed tungsten carbide) tip at the top. Suitable for drilling and edging on hard, soft, glued wood, chipboard, MDF panels, and more.
Other configurations available: shape, radius, fitting and diameter. To learn more — send an inquiry or call us.
Assembly router cutter with two replaceable HW (integral tungsten carbide) inserts, 1.5 mm thick, and one brazed Hc (brazed tungsten carbide) tip at the top. Suitable for drilling and edging on hard, soft, glued wood, chipboard, MDF panels, and more.
Other configurations available: shape, radius, fitting and diameter. To learn more — send an inquiry or call us.
Arbor: ISO-30 arbor
Maximum speed: up to 24 000 RPM
Type: CNC Router Tools
Description
Cutter composed of two replaceable HW (integral tungsten carbide) inserts, 1.5 mm thick, and one brazed Hc (brazed tungsten carbide) tip at the top.• Suitable for drilling and edging on hard, soft, glued wood, chipboard, MDF panels, and more.
• Used on CNC routers.
• Type of fixing: insert cutter.
• Body material: steel.
• Cutting edge material: HW.
Specifications
- Diameter (d): 20–30 mm
- Cutter width (b): 50 mm
- Cutting length (ltt): 120 mm
- Number of cutting edges (Z): 2+1
- Rotation: DX/RH (clockwise)
- Shank diameter (s): 20 mm
- Type: Assembly router cutter
- Body material: steel
- Cutting edge material: tungsten carbide (HW)
- Suitable materials: hard wood, soft wood, glued panels, chipboard, MDF
- Compatible machines: CNC routers
