Multicut spiral planing cutters Z=16
A0106
Detailed Description
Tungsten carbide spiral cutter with sixteen fractioned wings and two starting helices, engineered for premium planing of hardwoods, softwoods, and laminated panels. The lightened steel body reduces vibration and spindle load, delivering extended tool life and exceptional surface finish.
Other configurations available: shape, radius, fitting and diameter. To learn more — send an inquiry or call us.
Tungsten carbide spiral cutter with sixteen fractioned wings and two starting helices, engineered for premium planing of hardwoods, softwoods, and laminated panels. The lightened steel body reduces vibration and spindle load, delivering extended tool life and exceptional surface finish.
Other configurations available: shape, radius, fitting and diameter. To learn more — send an inquiry or call us.
Arbor: Brazed fixing
Maximum speed: up to 24 000 RPM
Type: Multicut Spiral Cutters
Description
This multicut spiral cutter features 16 fractioned wings for flawless planing results.• Two starting helices for smooth cut entry
• Lightened steel body minimizes vibration and machine load
• Suitable for hardwoods, softwoods, and laminated panels
• Z=12 and Z=8 versions available on request
Quick ISO-30 arbor change ensures fast tool swaps.
Specifications
- Number of cutting wings: 16
- Helices: two starting helices
- Body: lightened steel (–50% mass)
- Cutting edge material: tungsten carbide
- Function: planing
- Compatible machines: planers, copy-shapers, moulders
- Suitable materials: hardwoods, softwoods, laminated panels
- Recommended RPM: 8,000–12,000 RPM
- Recommended feed rate: 1.5–3 m/min
- Tool life: up to 600 m² of profile cut under standard conditions
